high quality pump mini vacuum pump electric air pump
Customized support: OEM, ODM
Brand Name: Desun
Model Number: DSP3035-XA
Place of Origin: Guangdong, China
Application: Other, Automotive Industry, Commercial Buildings, Family Homes, Industrial Utilities, Irrigation and Agriculture, Machining
Horsepower: Desun Standard
Power Source: Electric
Pressure: Low Pressure
Structure: Peristaltic Pump
Cable Length: Desun Standard
Outlet Size: 5.0mm
Voltage: 3.7V/4.5V/6V/12V/24V
Power: 6W
Product name: vacuum pump
Lifetime: >=500hours
Noise: ≤65dB (30cm away)
Max vacuum: <=-60Kpa(-450mmHg)
Max pressure: >=100Kpa(750mmHg)
vacuum flow: 3.5-8LPM
Weight: 85g
Duty work: Work a whole day continously
Certification: CE,RoHS
DSP3035-XA vacuum pump
Features
1. Life: Expected life span is 500hours.
2. One Year warranty.
3. Duty work: The pump can sustain heavy-duty work for a whole day. Continuous operation.
4. Working conditions: Applying to indoor and outdoor under temperature 45 deg C.
5. Working temperature: 5~45°C .
6. One week for samples, two week for bulk order.
7. Factory price + high quality + good after-sales service
Related model technical parameters
Voltage(V)
Power
Rated Current
tap O.D.
Vacuum flow
Maximum Pressure
DC 3.7V
6W
≤ 1600mA
Dia 5.0mm
3.5- 8.0LPM
≤ -60 Kpa
DC 4.5V
6W
≤ 1300mA
Dia 5.0mm
3.5- 8.0LPM
≤ -60 Kpa
DC 6V
6W
≤ 1000mA
Dia 5.0mm
3.5- 8.0LPM
≤ -60 Kpa
DC 12V
6W
≤ 500mA
Dia 5.0mm
3.5- 8.0LPM
≤ -60 Kpa
DC 24V
6W
≤ 250mA
Dia 5.0mm
3.5- 8.0LPM
≤ -60 Kpa
Application :
1. Household applications: white goods, small appliances, fans, electric screens, automatic window opening, floor cleaning robots,
vacuum cleaners, smart home systems.
2. Medical applications: medical pumps, sphygmomanometers, surgical tools, medical agitators, centrifuges.
3. Power tools: air pump, water pump, vacuum pump, oxygen generator, electric drill, electric screwdriver.
4. Commercial equipment: printers, copiers, shredders, projectors, scanners, cash registers, vending machines.
5. Personal care: hair dryer, electric shaver, beauty product, hair curler, steam hair straightener (water jet straight hair
outlet).
6. Health field: massager, adult toy.
7. Security field: surveillance system, camera, safe.
8. Industrial applications: robotic arms, printing equipment, automation equipment.
9. Other applications: electronic door locks, smart switches, robots, toys, smart cars, boats, intelligent wear, electronics, DIY,
etc.
The application scene pictures are just for your reference. We supply Full Customization Service, please contact us for the
details.
