Products Description

Features

1 This is mainly used for turbocharger cooling
2 This water pump has small power and long life
3 The DC brushless motor has good reliability, high efficiency and energy saving, and low noise
4 control mode: ON / OFF
5 Over-temperature protection: When the water pump exceeds the operation range, the water pump returns to normal operation when
the temperature returns to the appropriate operation range
6 reverse connection protection: positive and negative pole connection reverse water pump will automatically power off protection

Technical parameters

Working medium: antifreeze
Ambient temperature: -40℃~+150℃
Medium temperature: -40℃~+125℃,
Rated voltage: DC12.5V Voltage range: DC8V~DC16V
Weight: 330g
Life: ≥20000h
Protection level: IP67
Protection function: overheat protection

More technical parameters

The technical parameters above are only a few for your reference. You can tell us what you use for, then we'll offer you suitable pumps.

Dimensional drawing and working curve diagram

Widely used for mini aquarium,mini fish tank water circulation, desktop fountain, handicraft decoration water cycle, humidifier, medical equipment, beauty equipment.

We supply Full Customization Service, please contact us for the details.

Suppot both submersible and unsubmersible installation
